| Open Stand fast and easy process |
|
 |
Simple adjustment feature - one adjustment nut to align the conveyer to the sanding head - makes the process fast and easy |
|
Easy height adjustment—a thrust bearing below the handle and a nut above prevents the drum moving out of set position while sanding |
|
Extra wide conveyor to properly support stock over 480mm wide |
|
Drum carriage bolted to the base preventing any alignment issues |
|
INTELLISAND™ Technology - adjusts conveyor speed based on load prevents gouging and burning - provides a consistent finish |
| |
|
| Technical Information: |
|
Max. Thickness |
100mm |
|
Min. Thickness |
0.8mm |
|
Min. Length |
sanding – 60mm |
|
Max. Width of cut |
960mm (2 passes) |
|
Drum speed |
1740 RPM |
|
Conveyor Speed |
Variable 0-3metres / min |
|
Conveyor Motor |
Direct Drive, DC |
|
Main motor |
1 1/2 HP single phase |
 |
|
Dust port |
1 x 100mm |
Optional Accessories: |
|
Dimensions |
1460 x 860 x 1450mm |
|
Digital depth gauge |
|
Net weight |
155kg |
|
Castor wheels x 4 |
| |
 |
|
|
In-feed / out-feed tables |
| |
|
|
Closed stand with castor wheels |
| |
Download Flyer 152KB |
|
Pre cut abrasive rolls / abrasive cleaning stick |
| |
|
|
|
|
